[Lead screenshot to come: the AFV family is not placed in a game scene yet.]
| Primary Supplier | EADS |
| Designation | CH90220C Pocket Gun |
| Role | Self-propelled howitzer Built on the Leopard 4’s hull; turning, the turret’s underside clears the cab roof’s rear edge by 26 mm. Resupplied by a dedicated APC variant (planned), which slides the ammunition box in at the rear. |
| Length | 7.33 m (hull); 12.62 m with the gun |
| Width | 3.70 m over the skirts’ ERA |
| Height | 3.17 m to the roof; 3.19 m over the breech |
| Mass empty | classified |
| Mass combat | 64.6 tonnes in composite armour |
| Crew | 2, in the front row |
| Operation | |
| Drive | As the Leopard 4: tracks with a hub motor in every road wheel, 8 stations a side, and four hardpoints for dEM pods, with the tracks always down |
| Energy | Batteries, fuel cells, LH2 |
| Road speed | 65 km/h (18 m/s) cruising, 108 km/h (30 m/s) flat out, and as fast in reverse |
| Acceleration | 3 m/s² |
| Armament | 220 mm L42 binary-propellant howitzer (tube 9.24 m) in a fixed turret, elevation −9.6° to +70°. Layered tube (steel liner, titanium jacket, coolant, carbon-fibre casing) at 550 MPa peak (est.). Gun with cradle, recoil system and the breech’s ready box 10.9 tonnes (est.). 27 shells of 120 kg (est.) in the ammunition box, with 700 kg of propellant (est.). Muzzle velocity about 1,060 m/s (est.). Drones: two recon drone boxes a side in the turret, under sliding doors. |
| Range | Gun about 46 km, 55–65 km rocket-assisted |
| Point defence | Two 12 mm tri-barrel gatlings, on the glacis and on the rear deck |
| Protection | Composite armour, the turret armoured as the IFV’s with 179 ERA blocks; active defence with 2 launchers in the turret’s sides and 4 radar panels; NBC protection, mines and IEDs |
Technical drawings
