Asturcón (General Utility Vehicle type 14001A)

Only a basic blockout of this vehicle so far, and no variants as yet.

Three boxy, four-wheeled utility vehicles in green camouflage drive in line across a paved apron, past the open ramp of a large camouflaged landing barge.
Three Asturcóns in convoy on the strip at LZ Danjou, Celestia II, passing the big landing barge’s open ramp.
Main SupplierKNDS Navantia
DesignationGUV 14001A “Asturcón” General Utility Vehicle
RoleWheeled general purpose utility vehicle
Length5.70 m
Width2.70 m
Height2.35 m
Mass5 tonners
Crewupto 6
OperationCan be driven by hand, remotely by AR visor and slaved to another compatible vehicle.
DriveElectrical wheel hub motors on all weheels, LH2, fuel cells, batteries
SteeringAll wheel steering
Road speed72 km/h (20 m/s) cruising, 144 km/h (40 m/s) flat out
ArmamentNone in the basic version
ProtectionUp to 12.7mm HMG, NBC, reinforced vs. mines and IEDs

Technical drawings

Perspective drawing of the utility vehicle seen from ahead and off its left side.
Utility vehicle: three-quarter front view, perspective, not to scale.
Technical drawing of the utility vehicle, front view, with a scale bar.
.
Technical drawing of the utility vehicle, back view, with a scale bar.
Technical drawing of the utility vehicle, top view, with a scale bar.
Technical drawing of the utility vehicle, left side view, with a scale bar.
Technical drawing of the utility vehicle, right side view, with a scale bar.
