| Primary Supplier | EADS |
| Designation | 90200B Harpsichord |
| Role | Multiple rocket launcher Built on the Leopard 4’s hull and turret ring. The launcher box’s lift rams rise from a basket under the ring. It is the tallest vehicle the Droopy takes: kneeling, 113 mm under her ceiling. A rear door in the rear plate opens onto the compartment behind the cab. |
| Length | 7.33 m (hull) |
| Width | 3.70 m over the skirts’ ERA, the box as wide |
| Height | 3.02 m with the box stowed, as carried |
| Mass empty | classified |
| Mass combat | 66.7 tonnes (est.) |
| Crew | 2, in the front cab |
| Operation | |
| Drive | As the Leopard 4: tracks with a hub motor in every road wheel, 8 stations a side, and four hardpoints for weight-relieving EM pods, with the tracks always down |
| Energy | Batteries, fuel cells, LH2 tanks |
| Road speed | 65 km/h (18 m/s) cruising, 108 km/h (30 m/s) flat out, and as fast in reverse |
| Acceleration | 3 m/s² |
| Armament | 60 rockets of 200 mm in 220 mm tubes, 15 across and 4 high; each about 3.06 m long, nose to nozzle, and 230 kg. The box is 3.16 m long, on a turntable on the hull’s ring that turns ±117.5°, and elevates to +90°. |
| Range | |
| Point defence | Two 12 mm tri-barrel gatlings, on the glacis and on the rear deck’s slope |
| Protection | Composite armour 179 ERA blocks, radar panels. NBC, mines and IED protection |
Technical drawings
